Nederman FilterMax DX Series User Manual

16
JP3
230
120
100
0
JP4
4
3
2
1
1 2
34
1 2
34
1 2
34
1 2
34
1 2
34
1 2
34
5000
4500
4000
3500
3000
2500
2000
1500
1000
500
0
0
1000 3000 5000 7000 9000 11000 13000 15000 17000
Each FilterMax DX can be connected to
an existing central EX-fan or to an EX-fan
dimensioned specially for the system.
NB! Remove the clamp between 3 and 4
on the output contact before the cable
from the pilot box above is connected.
Total pressure, Pa
Air flow m
3
/h
An adequate fan can be selected from the
Nederman NCF EX-range. Please contact your
Nederman representative for dimensioning the
right fan capacity. To start the NCF EX fans a
Nederman Fan Starter PTC is recommended.
Calculated air pressure drop over the
filter is approximately 1200 Pa.
A lockable safety switch (EX-proofed if
FilterMax DX is in a risk zone) is recom-
mended for the whole electric system
including the fan.
FANS
CONNECTION OF 2 OR 3 PILOT BOXES
