Nederman NCF Series Instruction Manual

NCF
15
EN
3.2 Prohibited uses
Below is a list of specic uses that are prohibited:
• Operaon of the fan with non-gaseous uids or with uids with characteriscs
dierent from those dened to be used with the fan, since structural damage may be
caused to the fan with the possible risk of injury to persons and/or damage to things;
• Operaon of the fan in all types of system with pressures (present or even parally
generated by the fan) greater than 1.2 mes standard atmospheric pressure, since
structural damage may be caused to the fan with the possible risk of injury to persons
and/or damage to things;
• Operaon of the fan in all types of systems classied in accordance with the ATEX
direcve and that move potenally explosive uids, since risks of ignion/explosion
may arise with possible injury to persons and/or damage to things;
• Operaon of the fan in industrial chemical plants where the uid moved is highly
corrosive for the materials used in fan construcon, or in the presence of highly toxic
uids where the construcon methods of casings and the types of seal used are not
suitable for this specic applicaon, since structural damage may be caused to the fan
with the possible risk of injury to persons and/or damage to things;
• Operaon of the fan in mining industry plants and with underground installaons,
since addional risks not considered in the use of the fan above ground may arise,
with possible injury to persons and/or damage to things.
3.3 Life cycle of fan
The reliability of all components is guaranteed if they are properly maintained and if
Nederman original parts and accessories are used.
For safety reasons, guards in electrowelded wire must be replaced every 2 to 3 years.
If the fan is used at constant speed for two work shis every day equivalent to 16 hours,
calculated for 250 days per year, the expected life cycle for the impeller is equivalent to
40,000 hours, ie., 10 years.
In the specic case of operaon at variable speeds, the impeller life cycle must be assessed
on a case-by-case basis, and must also be agreed with Nederman.
Even if it has never been used, an impeller that has been stored for more than ten years
must be checked by Nederman for possible defects before it can be used.
3.4 Technical specicaons
3.4.1 Technical data 50 Hz fans (metric)
Table 3-1: Technical data 50 Hz fans (metric)
NCF 30/15 NCF 30/25 NCF 40/25 NCF 50/25 NCF 80/20 NCF 120/15 NCF 120/25 NCF 160/25
Capacity (m
3
/h) 1100 - 4400 1700 - 6500 2000 - 6700 1800 - 5900 2300 - 9100 5700 - 14400 3500 - 12400 4600 - 17900
Total
pressure (Pa)
1840 - 700 2440 - 920 3440 - 1410 4550 - 1690 3070 - 1150 2520 - 740 4500 - 2000 5030 - 1880
Motor power
(kW)
2,2 4 5,5 5,5 7,5 7,5 15 18,5
Speed (rpm) 2880 rpm 2905 rpm 2925 rpm 2925 rpm 2930 rpm 2930 rpm 2940 rpm 2940 rpm
Voltage (V)
Current (A)
230Δ/400Y
7,9/4,55
230Δ/400Y
13,6/7,8
230Δ/400Y
17,9/10,3
230Δ/400Y
17,9/10,3
230Δ/400Y
24,0/13,8
230Δ/400Y 230Δ/400Y 230Δ/400Y
*Reference standards: ISO 3744, ISO 3746, ISO 13347. Installaon Type D: ducted inlet, ducted outlet.
