NCF
29
EN
• Reduced by 10% for zinc plated oiled screws.
• Reduced by 20% for phosphor coated oiled screws.
• Reduced by 10% if the screw is ghtened with an impulse ghtener.
Table 6-2: Tightening torques M for bolts with ISO metric thread
d x pitch (mm) S r (mm²) 8.8 M (Nm) 10.9 M (Nm) 12.9 M (Nm)
6 x 1 20,1
1. 10,4 2. 15,3 3. 17,9
7 x 1 28,9 17,2 25 30
8 x 1,25 36,6 25 37 44
10 x 1,5 58 50 73 86
12 x 1,75 84,3 84,3 127 148
14 x 2 115 115 115 115
16 x 2 157 214 314 368
18 x 2,5 192 306 435 509
20 x 2,5 245 432 615 719
22 x 2,5 303 592 843 987
24 x 3 353 744 1060 1240
27 x 3 459 1100 1570 1840
30 x 3,5 561 1500 2130 2500
6.6 Spare parts
CAUTION! Risk of equipment damage.
Use only Nederman original spare parts and accessories.
Contact your nearest authorized distributor or Nederman for advice on technical service or
if you require help with spare parts. See also www.nederman.com.
Ordering spare parts
When ordering spare parts always state the following:
• Part number and control number (see the product idencaon plate).
• Detail number and name of the spare part (see www.nederman.com).
• Quanty of the parts required.
6.7 Recycling
The product has been designed for component materials to be recycled. Its dierent
material types must be handled according to relevant local regulaons. Contact the
distributor or Nederman if uncertaines arise when scrapping the product at the end of its
service life.
7 Troubleshoong
The following chart lists the main problems that may be encountered:
