CAUTION! Risk of equipment damage.
• The place of installaon of the fan must be kept clean. Any spills of oil or water not due
to the fan must be cleaned away as quickly as possible.
• The minimum installaon distances dened in this manual must always be respected to
guarantee correct operaon and the absence of addional risks. Incorrect posioning
could impair the correct operaon of the fan.
NOTE! Always use an-vibraon supports and joints to reduce to a minimum the
transmission of vibraons during fan operaon.
NOTE! During installaon, the conservaon of the minimum access spaces requested for
maintenance operaons must be veried.
4.1 Delivery check
If there are any damaged or missing parts when the product is delivered, nofy the carrier
and the local Nederman representave immediately.
4.2 General informaon
4.2.1 Fan orientaon
See Figure 6. NCF fans can be supplied with 9 dierent orientaons except for the NCF
30/15 that can only be supplied with 6 dierent orientaons.
The rotaon direcon of a fan is dened for an observer located on the transmission side.
4.2.2 Standard fan outlet posion for NCF fans
The standard NCF fans are delivered as RD0, shown in Figure 6. Other posions can be
delivered on request. Please contact your AB Ph. Nederman & Co representave for
assistance.
