22
INSTALLER INSTRUCTIONS
nekos products have been manufactured in accordance with safety standards and
conforms to the stipulations of current standards in force.
When correctly assembled, installed and used according to the present instructions, they
will not generate any danger for persons, animals or items.
Symbols used in the manual
DANGER
This indication draw the attention about potential dangers for safety and
health of peoples and animals.
English ................................................................................................................. 23
1. SECURITY RULES................................................................................................................ 23
2. TECHNICAL INFORMATION ABOUT FUNCTION................................................................ 24
3. FORMULAS AND RECOMMENDATIONS FOR INSTALLATION ........................................ 24
4. USE OF ACTUATOR IN ‘SYNCRO³’ VERSION .................................................................... 25
5. CONSTRUCTION AND STANDARDS .................................................................................. 25
6. TECHNICAL DATA ................................................................................................................ 26
7. ID PLATE AND MARKING DATA .......................................................................................... 27
8. ELECTRICAL POWER SUPPLY ........................................................................................... 27
9. INSTRUCTIONS FOR ASSEMBLY ....................................................................................... 28
10. ELECTRICAL CONNECTIONS ............................................................................................. 31
11. PROGRAMMING THE LIMIT SWITCHES ............................................................................. 32
12. CHECKING FOR CORRECT ASSEMBLY ............................................................................ 36
13. EMERGENCY MANOEUVRES, MAINTENANCE AND CLEANING ..................................... 36
14. TROUBLESHOOTING ........................................................................................................... 36
15. ENVIRONMENTAL PROTECTION ....................................................................................... 37
16. CERTIFICATE OF GUARANTEE .......................................................................................... 37
17. DECLARATION OF INCORPORATION (for a partly completed machine) AND EC
DECLARATION OF CONFORMITY ...................................................................................... 38
23
1. SECURITY RULES
CAREFULLY OBSERVE ALL THE FOLLOWING INSTALLATION INSTRUCTIONS TO ENSURE
PERSONAL SAFETY. IMPROPER INSTALLATION CAN SERIOUSLY ENDANGER SAFETY.
MANDATORY RISK ANALYSIS AND PROTECTION MEASURES.
The Nekos electrical actuators comply with the Machinery Directive (2006/42/EC), Standard IEC
60335-2-103 (Particular requirements for drives for gates, doors and windows) and other
directives and regulations indicated in the attached Declarations of Incorporation and CE
Conformity (at the end of the manual). According to the Machinery Directive, actuators are
“partly completed machinery” intended for incorporation into doors and windows. The
manufacturer/supplier of the window is required, with exclusive responsibility, to ensure the
compliance of the entire system with the applicable standards and to issue CE certification. We
strongly discourage any use of the actuators other than that specified and therefore, in any case,
the supplier of the complete system retains full liability.
For systems installed at a height of less than 2.5 m above floor level or other levels accessible
to users, the manufacturer/supplier of the window must conduct risk analysis regarding
potential harm (violent blows, crushing, wounds) caused to people by normal use or possible
malfunction or accidental breakage of the automated windows, and to implement suitable
protective measures in view of these. Such measures include those recommended by the
specified standard:
- controlling the actuators via a “deadman’s button” placed near the system and within the
operator’s field of view, to ensure that people are out of the way during operation. The
button must be placed at a height of 1.5 m and operated by key if accessible to the public;
or:
- use of contact safety systems (also included in the actuators) that ensure a maximum
closing force of 400/150/25 N, measured in accordance with paragraph BB.20.107.2 of
IEC 60335-2-103; or:
- use of non-contact safety systems (lasers, light grids); or:
- use of fixed safety barriers that prevent access to moving parts.
Automated windows are deemed adequately protected if they:
- are installed at a height of >2.5 m; or:
- have a leading-edge opening of <200 mm and a closing speed of <15 mm/s; or:
- are part of a smoke and heat evacuation system for emergency use only.
In any case, moving parts of windows that could fall below 2.5 m following breakage of a
system component need to be fixed or secured in order to prevent them from suddenly falling
or collapsing: e.g. the use of safety arms on bottom-hung windows.
The device is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lacking experience and knowledge. Do not allow
children to play with the fixed controls and keep any remote-control units out of their
reach.
The actuator is destined exclusively for installation indoors. For any special
application we recommend you consult the manufacturer beforehand.
After removing packaging, check for any damage on the appliance.
Always request exclusive use of original spare parts. Failure to respect this condition
could compromise safety and invalidate the benefits contained in the warranty for the
appliance.
In the event of any problems or queries, consult your agent or contact the
manufacturer directly.
