Nelson NCD+ User Manual

© 2016 Nelson Stud Welding, Inc. Page 23
All Rights Reserved. January 2016 Part No. 729-110-043 Rev. 1.02
ITEM
PART NUMBER
QTY
DESCRIPTION
SPARE?
31
751-650-222
1
SPRING ADJUSTMENT SCREW
32
751-650-221
1
INDEXING RING
33
524-005-097
1
SCREW, M5X5 FPSS
34
751-650-218
4
REAR LIFT ADJUSTMENT KNOB
35
524-005-331
1
SCREW, THUMB, SS SHEAR-LOC#928B-0305-010S
36
751-650-220
1
REAR SPRING ADJUSTMENT KNOB
37
751-650-214
1
REAR LABEL
38
524-005-320
2
SCREW, M2.5X8 MINI THREAD FORM
39
526-001-232
1
SPRING, GROUND SENSE WIRE
X
40
713-032-000
3
WIRE SPLICE
41
751-585-004
1
CABLE GROMMET
42
721-268-012
1
CONTROL CABLE ASSEMBLY
X
43
720-519-080
1
WELD CABLE ASSEMBLY
X
44
524-005-100
3
SCREW, M4X16 OHMS ZINC
45
751-650-502
1
BODY, WELDGUN, L.H., MOD., L.E.D., NCD+
46
751-650-501
1
BODY, WELDGUN, R.H., MOD., L.E.D., NCD+
47
511-011-131
1
SPARK SHIELD, CD, 46MM
48
751-650-012
3
PIN, LOCATING
49
524-005-106
2
SCREW, M5X25 FHSHCS DI
50
751-650-008
2
WASHER, LEG M5 ZINC
51
502-001-261
1
FOOT, CD GUN
52
504-001-056
2
LEG, 8MM X 110MM, SS
53
103-475-610
1
WIRE, BLACK, 18AWG, 4” OR .333’
54
751-614-005
1
PCB, NCD+ GUN L.E.D.
X
55
751-650-503
1
HOLDER, L.E.D. BOARD
X
