Nelson NCD+ User Manual

© 2016 Nelson Stud Welding, Inc. Page 22
All Rights Reserved. January 2016 Part No. 729-110-043 Rev. 1.02
8.2 Contact Gun with LED Option (751-650-610)
8.2.1 Parts List
ITEM
PART NUMBER
QTY
DESCRIPTION
SPARE?
1
751-650-009
1
CHUCK NUT
2
751-650-007
1
BELLOWS
3
524-005-097
2
SCREW, M5X5 FPSS ZINC
4
751-650-003
1
COVER, FRONT MACHINING
5
524-005-007
2
SCREW, M8X8 FPSS
6
751-650-006
1
FRONT BEARING
7
729-023-017
1
12MM D RETAINING RING
8
526-001-234
1
MAIN SPRING
9
751-650-210
1
WASHER SPRING
10
726-013-002
1
COLLET
11
751-585-021
1
E-RING
12
751-650-027
1
TRIGGER BUTTON
13
87-05-22
1
TRIGGER SPRING
14
751-650-022
1
M4 BRASS WASHER
15
751-650-211
1
TRIGGER ASM SWITCH
16
524-005-105
1
SCREW, M5X10 SHC DIN91
17
751-650-202
1
LIFTING ROD ASM
18
729-023-021
1
PIN, ROLL, CIRCUM 1.5X4
19
524-005-104
1
THICK M5 NUT
20
720-517-000
1
WELD CABLE JUMPER
21
751-650-209
1
WASHER, RESIDUAL
22
751-650-216
1
COIL ASM
23
751-650-217
1
COIL HOLDER
24
524-005-103
1
SCREW, M3X5 LHS DIN7984
X
25
751-650-213
1
ARMATURE, SPRING RETAINER
26
524-005-323
1
STANDOFF, HEX MMC#93655A091
27
526-001-266
1
COMPRESSION RING
28
524-005-330
1
SCREW, M3X10 FPSS MMC#92605A104
29
751-650-219
1
SPRING PRESSURE ADJUSTMENT NUT
30
524-005-324
1
SPACER MMC#92871A171
