NS20A & NS20N Heavy Duty Gun Page 15 Revision 1.20 2/19/08
DIMENSIONS AND SPECIFICATIONS
NELSON
NELSONNELSON
NELSON
7"
7"
13"
2.25"
1"
1.25"
9.25"
Length:
(less accessories) ........................................................................................... 13”
Basic Weight:
Includes standard legs and foot plus cable loop to cable spud .......... 7 lbs. 8 oz.
Working Weight:
Includes standard legs and foot plus four (4) feet of cable from gun handle.
(Note: Four (4) foot length of cable is normally supported by the operator
when in working position)............................................................... 10 lbs. 8 oz.
Shipping Weight:
Includes standard legs and foot plus approximately 7 feet of cable with
connectors normally supplied with gun............................................ 14 lbs. 8 oz
