Neptronic SKR Series - User Manual

Questions and Answers

C
Cassandra ShawJul 26, 2025
Why is there water accumulating under my Neptronic SKR?
- A
  Angela WolfeJul 27, 2025
  If you find water accumulating under your Neptronic Humidifier, several factors could be the cause. First, examine all drain couplings for leaks, obstructions, or incorrect slope. Ensure there are no drain traps installed on the drain line, as these should be removed. Next, check the water supply connection for any leaks. Also, verify that the clamp on the steam hose is properly tightened on the steam outlet of the evaporation chamber. Finally, inspect the evaporation chamber gasket inside the evaporation cover for any signs of leakage.
N
Natalie MartinAug 3, 2025
What to do if my Neptronic SKR Humidifier isn't operating and the alarm indicator is flashing?
- A
  Antonio SmithAug 3, 2025
  If your Neptronic Humidifier isn't operating and the alarm indicator is flashing, consult section 16 - Types of alarm in the manual to identify the specific alarm and find instructions on how to resolve it.
D
Daniel GreenAug 10, 2025
Why is the duct downstream of my Neptronic SKR Humidifier dispersion tube wet?
- C
  Christopher HarrisAug 10, 2025
  If the duct downstream of the dispersion tube is wet, it could be due to a few reasons. First, verify that the steam dispersion tube is installed correctly. Second, the humidifier's capacity might be too high; if so, consider installing a high limit duct humidistat (model HRDFS100). Lastly, if a high limit humidistat (HRDFS100) is available, check the setting of the DS1-3.
E
Eric WatersAug 17, 2025
How to troubleshoot a Neptronic Humidifier that does not operate (no alarm)?
- E
  emilymontgomeryAug 18, 2025
  If your Neptronic Humidifier isn't operating and there's no alarm, begin by checking the main power supply and fuses to ensure the humidifier is receiving power. Then, confirm that the airflow proving switch is detecting airflow by checking that the sensor tube is properly connected inside the duct and to the AFPS100, and that the green indicator on the airflow proving switch is on. Verify the ventilation system fan is operational. Ensure the AFPS100 or HRDFS100 is correctly located. Lastly, if available, check the high limit duct humidistat operation by setting the DS1-3 to the off position; replace the HRDFS100 if the humidifier then operates normally.

Summary

Foreword and Manufacturer Information

Foreword

Introduction to the manual and its purpose.

Manufacturer Presentation

Information about the manufacturer, Neptronic Ltd., and its products.

Humidifier Accessories and Overview

Description of Supplied Accessories

Lists the accessories included with the humidifier.

Humidifier Overview

Provides a visual overview of the humidifier components.

Humidifier Definition and Characteristics

Evaporation Chamber Definition

Defines the evaporation chamber and its components.

Humidifier Characteristics

Provides technical specifications and dimensions.

Mechanical Installation Guidelines

General Installation Recommendations

General advice and safety precautions for mechanical installation.

Humidifier Positioning

Guidelines for placing the humidifier for optimal access and ventilation.

Wall Mounting Instructions

Instructions and considerations for mounting the humidifier on a wall.

Steam Output Connections

Typical Steam Output Installation

Illustrates the standard setup for connecting steam output.

Steam Output General Recommendations

Rules to avoid condensation and ensure proper steam delivery.

Steam Distribution Piping

Steam Distribution Piping Recommendations

Specifies piping requirements for steam distribution.

Steam Dispersion Tube Location

Guidance on placing the steam dispersion tube in the duct.

Water Supply Connections

Water Supply Specifications

Details on connecting the water supply to the humidifier.

Drain Connections

Drain Connections and Air Gap

Instructions for making the drain connections, including air gaps.

Power Supply Connections

Electrical Safety and Connection

Instructions and precautions for connecting the electrical power.

Control Diagrams

Control Kit R Diagram

Wiring diagram for Control Kit R.

Control Kit D Diagram

Wiring diagram for Control Kit D.

Control System Details

Control Kit S Diagram

Wiring diagram for Control Kit S.

Control Components Description

Details on the functions of various control components.

Control Panel Interface

Control Panel Display Explained

Explains the indicators and buttons on the humidifier's control panel.

Control PC Board Description

P.C. Board Layout and Functions

Details the components and connections on the main control board.

Humidifier Operation Procedures

Start Up Procedure

Step-by-step guide to safely start the humidifier for the first time.

Description of SKR Operation

Explains how the humidifier functions during normal operation.

Shut-down Procedure

Humidifier Shut-down Steps

Instructions for safely shutting down the humidifier.

Maintenance Overview

General Maintenance Information

General information and importance of periodic maintenance.

Evaporation Chamber Cleaning Process

Detailed steps for cleaning the evaporation chamber.

Evaporation Chamber Maintenance Steps

Opening and Cleaning the Evaporation Chamber

Steps for opening and cleaning the evaporation chamber.

Reassembly and Post-Maintenance Startup

Steps for reassembling the chamber and post-maintenance startup.

Parts Identification and Listing

Exploded View of Components

Diagram showing all components of the humidifier.

Bill of Material

List of all parts with their part numbers and corresponding models.

Alarm Conditions and Troubleshooting

Types of Alarms and Consequences

Details on different alarm conditions and their consequences.

Troubleshooting Guide

Problem;Cause;Corrective Action Guide

Guide to identify and resolve common problems with the humidifier.

Electrical Diagram

Humidifier Wiring Schematic

Schematic showing the electrical connections and components.

Personal Notes

User Notes Section

Blank page for user notes.

General Conditions of Sale and Warranty

Sales and Warranty Terms

Terms and conditions related to purchasing and warranty.
