COR User Guide Page 10
COR-15 CONNECTION TO APEX SYSTEM
To connect a COR-15 to an APEX system, that APEX system must be equipped with an
available 1LINK port on an EnergyBar 832 or a 1LINK module. The EnergyBar 832 and
the 1LINK module each have three 1LINK ports; any of those 1LINK ports may be used.
However, if you also have WAV pumps and/or DC24 accessories, and other 1LINK and
DC24 devices such as WAV and PMUP pumps on a single EnergyBar 832 or 1LINK
module, calculate the total possible load of all connected 24VDC devices. Do not exceed
the maximum 24VDC load of the EB832 or 1LINK module, which is 100 watts. Add
another 1LINK module or EB832 in necessary.
• The COR15 may draw up to 60 watts
• WAVs draw up to 30 watts
• PMUP draws approximately 17 watts
• DŌS draws up to 22 watts
• GRO draws approximately 20 watts
Do NOT connect a COR-15 driver to a DOS’
1LINK port or a Trident’s 1LINK port.
COR DRIVER FIRMWARE UPDATE
After initially connecting the COR-20 or COR-15 to your APEX System, and after any
subsequent APEX system firmware or AOS update, check the COR driver’s installed
firmware version, and update it if it shows as OLD.
If you have an APEX (2016), go to the Modules page in either APEX Local or APEX
Fusion. Look in the SWRev column; if it says OK for your COR, no update is needed. If
it shows OLD, then click on the COR line, choose Update Firmware from the Action
menu, then click the orange Update APEX button
