COR User Guide Page 14
Logo Color
Status Meaning and 8-LED Bar Indication
Solid
Orange
• The COR driver is operating normally and is communicating with the APEX
system. If a COR-20 is being used in standalone mode, this also indicates
normal operations.
• The number of LEDs lit on the 8-LED bar indicates the current pump speed.
There are 16 speed levels when in standalone mode.
Flashing
Orange
• The COR driver is in fallback mode and is attempting to communicate with
an APEX base unit.
• The number of LEDs lit on the 8-LED bar indicates the current pump speed.
Pink
• The COR pump has been manually turned OFF using the left COR button or
by using the COR tile on the APEX Classic, APEX Local, or APEX Fusion
dashboard.
• None of the small LEDs will be lit.
Green
• One of these three conditions exist:
o FeedA has been activated using the right COR button
o FeedA has been activated through the APEX
o The COR driver is in Minimum Speed Calibration Mode
• The number of LEDs lit on the 8-LED bar indicates the current pump speed
Blue
• The COR driver is in Maximum Speed Calibration Mode
• The number of LEDs lit on the 8-LED bar indicates the current pump speed
Red
• An error condition exists. When the status LED is red, one of the LEDs of 8-
LED bar will flash to indicate the specific issue detected.
o The COR driver has detected an overcurrent condition (LED #1, #4,
or #5 may be flashing) This may indicate that the pump’s intake is
blocked or a foreign object is preventing the impeller from rotating
o The input power voltage is too high (LED #2 will be flashing)
o The COR-20 driver is connected to an APEX system but it has no
24VDC input power (LED #3 will be flashing)
o The input power voltage is low (LED #3 will be flashing)
o The COR pump is running while dry or out of water (LED #6 will be
flashing)
o The internal temperature of the pump is high (LED #7 will be
flashing)
Yellow
• The COR driver’s internal firmware is being updated by the APEX
Not Lit
• One of these conditions exist:
o The COR-15 driver’s 1LINK cable is disconnected
o The COR-20 in Standalone Mode has no 24VDC power
o The COR-15 or COR-20 driver has suffered a failure
