Net Optics Gig Zero Delay Tap User Manual

Gig Zero Delay Tap & 10/100/1000BaseT Tap
11
Specications
Environment
Operating Temperature: 0˚C to 40˚C
Storage Temperature: -10˚C to 70˚C (TP-CU3 and TP-CU3-DC)
-10˚C to 45˚C (TP-CU3-ZD and TP-CU3-ZD-DC)
Relative Humidity: 10% min, 95% max, non-condensing
Power
Power Consumption
TP-CU3-ZD and TP-CU3-ZD-DC: 8W typical, 30W maximum
TP-CU3 and TP-CU3-DC: 8W typical, 10W maximum
Power Supply
Input: 100-240VAC, 0.5A, 47-63Hz
Output: 12V 1.5A (TP-CU3 and TP-CU3-DC)
12V 3A (TP-CU3-ZD and TP-CU3-ZD-DC)
-48V Power Supply
Input: -48V DC typical, -36V DC min, -75V DC max
DC Receptacle: Terminal peak, 12-14 gauge wire
Power Over Ethernet (POE)
Fully compatible with POE applications
The Tap passes POE power (like a cable)
The Tap does not supply or consume POE power
Latency (network-to-network & network-to-monitor)
@ 1000 Mbps: 0.75 µsec
@ 100 Mbps: 1.4 µsec
@ 10 Mbps: 10 µsec
Mechanical
Dimensions: 1.1” high x 9.9” deep x 5.55” wide (TP-CU3-ZD)
Dimensions: 1.1” high x 6.4” deep x 5.55” wide (TP-CU3)
Cable Interface
Copper Cable Type: CAT5e
Link Distance Supported: 100 meters
