SCREENGUARD

™

INSTALLATION AND USER MANUAL

REPLACEMENT PARTS

Part Description Cat. No. Qty.

7.3 Hydraulic Relay Assembly 71965-000414 1 set

Hydraulic Relay Assembly

Part Description Cat. No. Qty.

7.3.1 Dorot SG 71680-000800 1

7.3.2 Brass Connector Adaptor 3/8" X 1/4" 1

7.3.3 Brass Connector 1/4" X 1/4" F-F 1

7.3. 4 Plug in Metal Connector 8mm X 1/4" 1

7.3. 5 Plug in Metal Connector 90 deg 8mm X 3/8" 2

The Hydraulic Relay Assembly consists of the following parts

Aquative DC Version 01 Assembly

The Aquative DC Version 01 Assembly consists of the following parts

Part Description Cat. No. Qty.

7.1 Aquative DC Version 01 Assembly 71965-000261 1 set

Part Description Cat. No. Qty.

7.1.1 Aquative DC Version 01 35500-001905 1

7.1. 2 Plug in Metal Connector 8mm X 1/8" 2

7.1. 3 Plug in Metal Connector 90 deg 8mm X 1/8" 1

Part Description Qty.

11.1 M10 Plain Washer A2x70 12

11.2 M10 Hex Nut A2x70 12

Washers and Nuts set

The Washers and Nuts set consists of the following parts

Part Description Cat. No. Qty.

11 10mm SS Washer and Nuts, 12 pcs 71965-000256 1 set

Seal Kit

The Seal Kit consists of the following parts

Description Cat. No. Qty.

Complete O-ring and gasket kit for SG H ﬁlters 71965-000450 1 set

Part Description Qty.

9; 5.5 Cover Gasket 2

10; 2.3; 3.2 O-ring 2
