T E C H L I N E A S ™ D E S I G N G U I D E
NETAFIM @BCL@C40BDC65.doc 21/12/2009 10
STANDARD “GRID” LAYOUT:
 Manifolds should be set in 50mm – 100mm from hard scapes and planting areas.
 Manifolds may be PVC, LDPE Poly Pipe (refer table below).
 Manifolds must be sized to accommodate the flow of the zone without exceeding 1.6
metres per second velocity.
(Zone Water Requirement calculations are on page 10).
 Start rows of Techline AS™ 50mm – 100mm away from the edge of hard scapes, and
move across the area with equal row spacing that does not exceed the
recommendations of Table 1.
(The 50mm setback will help provide enough moisture to
prevent heat damage to plant material generated by hard scapes such as concrete or
asphalt).
 Start rows about 100mm away from planting beds.
STANDARD “LITE” LAYOUT:
 Water being supplied to the zone is split with a “T-piece” into two directions.
 Weave Techline AS™ back and forth throughout the planting area with evenly spaced
rows.
 Indent the tubing 50mm – 100mm from hardscapes and planting areas.
 Water is being split into two separate paths that meet in the middle; the maximum
length of the lateral can be twice the stated limit in Table 2.
 To determine the maximum amount of Techline AS™ you can use in the zone, simply
double the maximum length stated in Table 2.
