Space requirements and system cabinet dimensions
When unpacking your system cabinet, you must make sure that you have enough room
to remove the system cabinet from the packing material. Also make sure that the
intended location for the system cabinet is large enough for you to move the cabinet into
place.
Required space for unpacking the system cabinet
The following table defines the requires space needed to unpack and install your system cabinet:
Dimensions U.S.
Metric Shipping ramp length
80 in. 203.2 cm
Clearance beyond the ramp for
cabinet mobility
72 in.
182.9 cm Shipping pallet depth
59 in. 149.9 cm
Shipping pallet width 42 in.
106.6 cm Shipping pallet and packaging height
86 in. 218.4 cm
Total rack space, 42U 73.5 in.
186.7 cm Rail load capacity
Supports all current systems Supports all current systems
Empty weight ~400 lbs (~181 kg) lbs
~ 181 kg Fully loaded ship weight
Up to 1,800 lbs Up to 816.5 kg
Fully loaded static weight Up to 2,700 lbs
Up to 1,224.7 kg Front service clearance
47.2 in. 120 cm
1465
