NetApp ASA C Series System Documentation

Controller module cover
Thumbscrew
4. Align the end of the controller module with the opening in the chassis, and then gently push the
controller module halfway into the system.
5. Plug the power cable into the power supply and reinstall the power cable retainer.
6. Insert the USB flash drive into the USB slot on the controller module.
Make sure that you install the USB flash drive in the slot labeled for USB devices, and not in the USB
console port.
7. Push the controller module all the way into the chassis:
a. Place your index fingers through the finger holes from the inside of the latching mechanism.
b. Press your thumbs down on the orange tabs on top of the latching mechanism and gently push the
controller module over the stop.
c. Release your thumbs from the top of the latching mechanisms and continue pushing until the
latching mechanisms snap into place.
The controller module begins to boot as soon as it is fully seated in the chassis. Be prepared to
interrupt the boot process.
The controller module should be fully inserted and flush with the edges of the chassis.
1. Although the environment variables and bootargs are retained, you should check that all required boot
environment variables and bootargs are properly set for your system type and configuration using the
printenv bootarg name command and correct any errors using the setenv variable-name
<value>
command.
a. Check the boot environment variables:
▪
bootarg.init.boot_clustered
▪
partner-sysid
▪
bootarg.init.san_optimized for All SAN Array
▪
bootarg.init.switchless_cluster.enable
b.
If External Key Manager is enabled, check the bootarg values, listed in the
kenv ASUP output:
▪
bootarg.storageencryption.support value
▪
bootarg.keymanager.support value
▪
kmip.init.interface value
▪
kmip.init.ipaddr value
▪
kmip.init.netmask value
▪
kmip.init.gateway value
c.
If Onboard Key Manager is enabled, check the bootarg values, listed in the kenv ASUP output:
206
