c. Gently pull the controller module a few inches toward you so that you can grasp the controller module
sides.
d. Using both hands, gently pull the controller module out of the chassis and set it on a flat, stable
surface.
Step 2: Move the power supplies
You must move the power supply from the impaired controller module to the replacement
controller module when you replace a controller module.
1. Rotate the cam handle such that it can be used to pull power supply out of the controller module while
pressing the blue locking tab.
CAUTION:
The power supply is short. Always use two hands to support it when removing it from the controller module
so that it does not suddenly swing free from the controller module and injure you.
2. Move the power supply to the new controller module, and then install it.
3. Using both hands, support and align the edges of the power supply with the opening in the controller
module, and then gently push the power supply into the controller module until the locking tab clicks into
place.
The power supplies will only properly engage with the internal connector and lock in place one way.
To avoid damaging the internal connector, do not use excessive force when sliding the
power supply into the system.
Step 3: Move the NVDIMM battery
To move the NVDIMM battery from the impaired controller module to the replacement
controller module, you must perform a specific sequence of steps.
You can use the following illustration or the written steps to move the NVDIMM battery from the impaired
controller module to the replacement controller module.
431
