Air duct locking tabs
Risers
Air duct
Remove the NVRAM card
Replacing the NVRAM consist of removing the NVRAM riser, Riser 1, from the controller
module, disconnecting the NVRAM battery from the NVRAM card, removing the failed
NVRAM card and installing the replacement NVRAM card, and then reinstalling the
NVRAM riser back into the controller module.
1. If you are not already grounded, properly ground yourself.
2. Remove the NVRAM riser, Riser 1, from the controller module:
a. Rotate the riser locking latch on the left side of the riser up and toward the fans.
The NVRAM riser raises up slightly from the controller module.
b. Lift the NVRAM riser up, shift it toward the fans so that the sheet metal lip on the riser clears the edge
of the controller module, lift the riser straight up out of the controller module, and then place it on a
stable, flat surface so that you can access the NVRAM card.
812
