1 Orange release latch for drive 1
2 Orange release latch for drive 2
3 Orange release latch for drive 3
4 Orange release latch for drive 4
5 Orange release latch for drive 5
6 Orange release latch for drive 6
7 Orange release latch for drive 7
8 Orange release latch for drive 8
9 Orange release latch for drive 9
10 Orange release latch for drive 10
11 Orange release latch for drive 11
b. Raise the drive handle to vertical.
c. Use the handle to lift the drive from the drive drawer.
d. Place the drive on a flat, static-free surface and away from magnetic devices.
Attention: Possible loss of data access – Magnetic fields can destroy all data on the drive and cause irreparable
damage to the drive circuitry. To avoid loss of data access and damage to the drives, always keep drives away from
magnetic devices.
6. Remove the drive drawer:
a. Locate the plastic release lever on each side of the drive drawer.
