HyPer 9 IS User Manual Revision 06
NetGain Motors, Inc.
Page 21 of 27
27
DRIVER OUTPUT
2
PWM Output
Active low Internal diode to coil
return
Main Contactor, Brake, Valve
28
DRIVER OUTPUT
3
PWM Output
Active low Internal diode to coil
return
Main Contactor, Brake, Valve
29
DRIVER OUTPUT
4
PWM Output
Active low Internal diode to coil
return
Main Contactor, Brake, Valve
30
DIGITAL OUTPUT
1
Digital Output
active low No internal diode to
coil return
Buzzer-Fan-ON/OFF valve
31
DIGITAL OUTPUT
2
Digital Output
active low pull-down No internal
diode to coil return
Buzzer-Fan-ON/OFF valve
32
MOTOR
THERMAL PROBE
Analog Input
5V 1KΩ pull-up
Motor Temperature Probe
33
ENCODER 1B /
ENCODER 1 Cos
Peripheral Input
4V 470Ω pull-up, VL<=1.5V,
VH>=3.4V / 0,5 4,5 mV input
Quad Encoder Channel B / Sin/Cos
Encoder Cos
34
ANALOG INPUT 5
Analog Input
0÷12V 125KΩ pull-down
TO BE ASSIGNED
35
+5V OUT
Supply Output
5V ±5% 200mA
12V Supply
