NetGain Motors HyPer 9 IS User Manual

HyPer 9 IS User Manual Revision 06 NetGain Motors, Inc. Page 24 of 27
Temperature
defined by the user via related parameter.
21
Motor 1 High
Temperature
Motor 1 temperature is above the motor Start Cutback
Temperature defined by the user via related parameter.
Limiting
22
Motor 2 High
Temperature
Motor 2 temperature is above the motor Start Cutback
Temperature defined by the user via related parameter.
Limiting
23
Motor 1 Temp Sensor
Fault
Motor 1 temperature sensor value is out of permitted range.
Limiting
24
Motor 2 Temp Sensor
Fault
Motor 2 temperature sensor value is out of permitted range.
Limiting
25
High Voltage
Key-switch Voltage or Capacitors Voltage is above the Controller
Starting Cutback Voltage defined by the user via related
parameter.
Limiting
26
Low Voltage
Key-switch Voltage or Capacitors Voltage is below the Controller
Starting Cutback Voltage defined by the user via related
parameter.
Limiting
27
Microprocessor Over
Temperature
Microprocessor temperature is above 125°C.
Blocking
28
+5V Supply Failure
+5V supply is outside the +5V ± 10% range.
Blocking
29
+12V Supply Failure
+12V supply is outside the +12V ± 10% range.
Blocking
30
Encoder 1 Fault
Sin/Cos inputs values are above/below the fault thresholds or spin
sensor offset is not right.
Blocking
31
Encoder 2 Fault
Sin/Cos inputs values are above/below the fault thresholds.
Blocking
32
Driver Output 1
Open/Short
Driver Output 1 is either opened or short-circuited.
Blocking
33
Driver Output 2
Open/Short
Driver Output 2 is either opened or short-circuited.
Blocking
34
Driver Output 3
Open/Short
Driver Output 3 is either opened or short-circuited.
Blocking
35
Digital Output 1
Open/Short
Digital Output 1 is either opened or short-circuited.
Blocking
36
Digital Output 2
Open/Short
Digital Output 2 is either opened or short-circuited.
Blocking
37
EEPROM Failure
Error during read/write operation in EEPROM memory.
Blocking
38
EEPROM Corrupted
Memory CRC doesn't match.
Blocking
39
Driver Output 4
Open/Short
Driver Output 4 is either opened or short-circuited.
Blocking
