Hardware Setup
10
AC1450 Smart WiFi Router
The WiFi and WPS buttons toggle the WiFi and WPS functions on and off.
• W
iFi On/Off button. Pressing and holding this button for 2 seconds turns on and off the
2.4 GHz and 5 GHz wireless radios. If the Wireless LED is lit, the wireless radios are on.
If this LED is off, the wireless radios are turned off and you cannot connect wirelessly to
the router.
• WPS button.
You can use this button to use WPS to add a wireless device or computer
to your wireless network. The Wireless LED blinks blue when the router is trying to add
the wireless device or computer. The LED stays solid blue when wireless security is
enabled in the router.
Rear Panel
The rear panel has the connections and buttons shown in the following figure.
USB 3.0 Ethernet Internet
Power On/Off
Power connector
port
LAN ports 1–4
Reset
buttonport
Figure 3. Router rear panel
The Reset button restores the factory settings. See Factory Settings on page 123.
