Wireless Cable Gateway CG3000D/CG3100D User Manual
Wireless Configuration 2-11
v1.0, September 2009
2. In the main menu, select Wireless Settings. Scroll down to the WPS section of the screen:
WPS automatically
selects WPA-PSK
if security is disabled.
Figure 2-4
Note: WPS is incompatible with WEP security. If WEP is configured in the gateway
then WPS cannot be enabled.
3. Select Enable in the WPS Config field and click Apply.
4. In the WPS Method field, select Push Button.
5. Click Start WPS or push the
WPS button on the front panel of the gateway.
• The WPS LED on the front of the gateway begins to blink.
• The gateway tries to communicate with the client for 2 minutes.
• If the Security Option in the Wireless Settings screen was set to Disabled, the gateway
automatically changes it to WPA-PSK (including a PSK security password).
6. Go to the client wireless computer, and run a WPS configuration utility. Follow the utility’s
instructions to click a WPS button.
When the gateway adds the WPS client, it sends the SSID and WPA-PSK or WPA2-PSK
configuration to the client.
