Connect to the Gateway
9
Wireless Cable Voice Gateway CG3700EMR-1CMNDS
Gateway Rear Panel
The rear panel has the connections and buttons shown in the following figure.
Power adapter input
Ethernet LAN ports
Coaxial cable connector
Power On/Off button
Reset button
Phone port
USB port (optional)
Figure 2. Rear panel connections and buttons
The rear panel includes the following connections, viewed from top to bottom:
• Phone port. Connect a telephone to this port using an analog phone line.
• T
wo Gigabit Ethernet LAN ports. Use these ports to connect local computers.
• Coaxial cable connector. Attach
a coaxial cable to the cable service provider connection.
• Power adapter input. Connect the power adapter unit here.
• Power On/Off button. Press to turn on power
. Press again to turn off power.
• Reset button.
You can return the gateway to its factory settings. Press and hold the
Reset button for over seven seconds. The gateway resets and returns to its factory
settings. See Factory Default Settings on page 72.
