NETGEAR D6300 Installation Guide

3
Install Your Modem Router
Note: Keep your modem router in a vertical position.
1. Con
nect the router to your Internet service.
You can connect either directly to a DSL line or to a fiber/cable
mo
dem.
 T
o connect to a DSL line:
a. Inst
all an ADSL microfilter between the phone line and the
phone.
b. Co
nnect the ADSL port of the modem router to the ADSL
port of the microfilter
c. Use an ADSL micro
filter for every phone line in the house if
your modem router and telephone connect to the same
phone line.
Plugs into the ADSL line

NETGEAR D6300 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Channels quantity	2 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Rack mounting	-
Frequency range	2.4 - 5 GHz
USB ports quantity	2
Minimum system requirements	Internet Explorer 5.0, Firefox 2.0, Safari 1.4, Google Chrome 11.0
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Product color	Black
Flash memory	128 MB
Certification	RoHS, CEC, WEEE, Wi-Fi
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	255 mm
Width	205 mm
Height	77 mm
Weight	654 g
