NETGEAR EAX20 User Manual

10.
Within four minutes, go to the WiFi device and use its WPS software to join the WiFi
network.
11.
To verify that the WiFi device is connected to the extender’s WiFi network, select
Settings > Connected Devices.
The WiFi device displays onscreen.
Deny access to a computer or WiFi device
By default, access control is disabled so that it is easy for you to connect to the extender’s
WiFi networks.
You can deny network access to specific computers and WiFi devices based on their
MAC addresses. Each network device is assigned a MAC address, which is a unique
12-character physical address, containing the hexadecimal characters 0–9, a–f, or A–F
only, and separated by colons (for example, 00:09:AB:CD:EF:01). Typically, the MAC
address is on the label of the WiFi device. If you cannot access the label, you can display
the MAC address using the network configuration utilities of the computer. You might
also find the MAC addresses on the Connected Devices page (see View connected
devices on page 26).
To use WiFi access control to deny access:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 60.
A login page displays.
3. Enter your admin email address and password and click the LOG IN button.
The Status page displays.
4. Enter your admin user name and password and click the LOG IN button.
User Manual35Extender Network Settings
AX1800 4-Stream WiFi Mesh Extender

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
