NETGEAR EAX20 User Manual

Back Panel
The back panel of the extender provides a Reset button, Ethernet ports, and a DC power
connector.
Figure 3. Back panel
The back panel contains the following components:
1. Reset button. Pressing this button resets the extender. If the Reset button is pressed
for at least seven seconds, the Power LED blinks amber, and the extender returns
to its factory settings.
2. Ethernet ports. Use the four Gigabit Ethernet RJ-45 LAN ports to connect the
extender to LAN devices.
3. DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
User Manual9Overview
AX1800 4-Stream WiFi Mesh Extender

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
