NETGEAR EX6120 User Manual

Maintain and Monitor the Extender
39
AC1200 Dual Band WiFi Range Extender
To reset the extender to factory default settings, you can either use the Factory Reset button
on the side panel or log in to the extender and reset it.
For a list of factory default settings, see Factory Default Settings on page 47.
 To use the Factory Reset button to return the extender to factory default settings:
CAUTION:
This process erases any settings that you configured in the extender.
1. Insert a straightened paper clip into the hole of the Factory Reset button and hold it for
about seven seconds.
Factory Reset button
2. Release the button.
CAUTION:
Do not try to go online, turn off the extender, shut down the computer, or
do anything else to the extender until it finishes restarting.
The extender resets and restarts. This process takes about one minute.
 To log in to the extender and reset the extender’s to factory settings:
CAUTION:
This process erases any settings that you configured in the extender.
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.

NETGEAR EX6120 Specifications

General

Type	Network transmitter
Browser supported	Microsoft Internet Explorer 8.0, Firefox 20, Safari 5.1, Google Chrome 25.0
Maximum transfer distance	- m
LED indicators	Yes
Antennas quantity	2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WEP, WPA, WPA2-PSK, WPS
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	38 mm
Width	74 mm
Height	122 mm
Weight	293 g
