Overview
6
AC1200 Dual Band WiFi Range Extender
Meet Your Extender
Before you install your extender, familiarize yourself with its LEDs, buttons, and port.
Front Panel
Power LED
WPS LED
Router
Link LED
Device
Link LED
Figure 1. Front panel LEDs
Side Panels
Factory
Reset
Button
WPS button
Power On/Off
Power connector
(varies by region)
Ethernet port
Power connector
(varies by region)
button
Figure 2. Buttons and port on the side panels

Table of Contents

Other manuals for NETGEAR EX6120

Preview: Quick Start
Quick Start20 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR EX6120 and is the answer not in the manual?

NETGEAR EX6120 Specifications

General IconGeneral
TypeNetwork transmitter
Browser supportedMicrosoft Internet Explorer 8.0, Firefox 20, Safari 5.1, Google Chrome 25.0
Maximum transfer distance- m
LED indicatorsYes
Antennas quantity2
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Security algorithmsWEP, WPA, WPA2-PSK, WPS
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN (RJ-45) ports1
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth38 mm
Width74 mm
Height122 mm
Weight293 g
