NETGEAR EX6400 User Manual

Get to Know Your Extender
6
AC1900 WiFi Mesh Extender Essentials Edition
Front Panel and Side Panel LEDs and Buttons
The LEDs are located on the front panel. A switch and buttons are located on the side panel
and an Ethernet port is located on the bottom panel.
Router Link LED
Client Link LED
Power LED
WPS LED
Access Point/
Power On/Off button
WPS button
Ethernet port (on the bottom)
Factory Reset button
Router Arrow LED
Client Arrow LED
Extender switch
Figure 1. Extender front panel and side panel
Table 1. LEDs
LED Description
Router Link LED
This LED indicates the connection between the extender and the router
or access point.
• Solid green. Best connection.
• Solid amber. Good connection.
• Solid red. Poor connection.
• Off. No connection.
Client Link LED
This LED indicates the connection between the extender and a
WiFi-enabled computer or mobile device.
• Solid green. Best connection.
• Solid amber. Good connection.
• Solid red. Poor connection.
• Off. No connection.
Power LED
• Solid amber. The extender is booting.
• Solid green. The
extender is powered on.
• Off. The
extender is powered off.
WPS LED
• Solid green. WiFi security is enabled (WPA or WPA2).
• Blinking green. The
extender is making a WPS connection.
• Off. WiFi security is not enabled.

NETGEAR EX6400 Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in power socket	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	1900 Mbit/s
Product color	White
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	81.4 mm
Width	161 mm
Height	44.5 mm
Weight	300 g
