NETGEAR GS308PP User Manual

6SHFLĬFDWLRQV
6SHFLĬFDWLRQ Description
Network interfaces 8 Gigabit Ethernet RJ-45 ports that support 1G, 100 M, and 10 M
8 PoE/PoE+ ports
Power adapter input Power cord varies by region.
Power adapter output The switch supports two power adapters:
• 90W: 54V @ 1.66A
• 130W: 54V @ 2.4A
Max PoE budget The maximum budget for each power adapter is as follows:
• 90W: 83W PoE
• 130W: 123W PoE
Dimensions
(W x D x H)
9.3 x 4.0 x 1 in. (236 x 102 x 27 mm)
Weight 1.32 lb (0.6 kg)
Operating temperature 32–104°F (0–40°C)
Operating humidity 10%–90% relative humidity, noncondensing
Compliance FCC class A, CB, CE class A, VCCI class A, RCM class A, KC, BSMI,

NETGEAR GS308PP Specifications

General

Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Jumbo frames	9216
Latency (1 Gbps)	3 µs
MAC address table	4000 entries
Packet buffer memory	0.192 MB
Packet forwarding rate (1 Gbps)	1448000 pps
Certification	CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI, BSMI, KC
Product color	Black
LED indicators	Activity, Link, PoE, Power, Speed
Housing material	Metal
Mean time between failures (MTBF)	2752476 h
Input current	1.66 A
DC input voltage	54 V
Power consumption (max)	87.9 W
Total Power over Ethernet (PoE) budget	130 W
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet (PoE) type supported	PoE+
Heat dissipation	300.6 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	102 mm
Width	236 mm
Height	27 mm
Weight	600 g
