NETGEAR M4100 Series Hardware Installation Guide

Technical Specifications
28
NETGEAR Managed Switch
Table 6. Fast Ethernet switches physical specifications
Fast Ethernet Switches M4100-26-POE
(FSM7226P)
M4100-50-POE
(FSM7250P)
M4100-D10-POE
(FSM5210P)
Interface
(AutoUplink on all RJ-45
ports)
24 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
24 PoE ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
48 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
48 IEEE802.3af PoE
ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
8 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
8 IEEE802.3af PoE
ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
Bandwidth 6.4 Gbps 9 Gbps 4.8 Gbps
Weight (Kg) 4.13 4.96 1.4
Dimensions
(W x D x H) mm
440 x 257 x 43.2 440 x 310 x 43.2 328 x 169 x 43.2
Mean time between failure
(MTBF)
242,281.66 hrs 163,019.5 hrs 579,985.8 hrs
Heat dissipation (Btu/hr) 1,557.77 1,661.39 hrs 298.04
Acoustic noise (dB)
(ANSI-S10.12)
37.3 dB @ 25°C 38.9 dB @ 25°C 0
Maximum power
consumption (W)
(100–240V AC, 50–60 Hz)
456.29 486.64 87.30

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
