NETGEAR M4100 Series Hardware Installation Guide

4
1
1. Introduction
The NETGEAR ProSafe® 4100 series managed switches provide state-of-the-art,
high-performance, IEEE-compliant network solutions. They include powerful management
features that you can use to eliminate bottlenecks, boost performance, and increase productivity.
The M4100 Series switches include the following:
M4100-26G
M4100-50G
M4100-26-POE
M4100-26G-POE
M4100-50G-POE+
M4100-50-POE
M4100-D10-POE
M4100-D12G
M4100-12GF
M4100-D12G-POE+
M4100-24G-POE+
M4100-12G-POE+
This guide describes hardware installation and basic troubleshooting for these managed
switches.
These switches can be freestanding, wall mounted, or rack mounted in a wiring closet or an
equipment room. For information about features for each product, visit the NETGEAR website at
http://www.netgear.com.
Front Panels and LEDs
The following figures show the front panels of the ProSafe 4100 series managed switches.
The front panel contains LEDs, a Reset button, a USB flash port, RJ45 ports, copper
(RJ-45)/fiber (SFP) combo ports, and USB console selection slide switch, and USB console
port.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
