NETGEAR N300 WNR2000v5 User Manual

Hardware Setup
8
N300 WiFi Router
You can use the LEDs to verify status and connections. The following table lists and
describes each LED and button on the front panel of the router.
Table 1. LED and button descriptions
LED Description
WiFi On/Off
button with LED
Pressing this button for two seconds turns the WiFi radio in the router on and off. If this LED
is lit, the WiFi radio is on. If this LED is off, the WiFi radio is turned off and you cannot use
WiFi to connect to the router.
WPS button with
LED
This button lets you use WPS to join the WiFi network without typing the WiFi password.
The WPS LED blinks during this process and then lights solid.
Power
• Solid green. The power is on, and the router is ready.
• Solid amber. When you apply power to the router
, the Power LED lights and turns
amber within a few seconds. This indicates that the self-test is running.
• Blinking green. A
firmware update is in progress.
• Off. Power is not supplied to the router.
Internet
• Solid green.
• Solid amber.
• Off.
WiFi
• Solid green. The WiFi radio is operating.
• Off. The
wireless radio is off.

NETGEAR N300 WNR2000v5 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Frequency band	2.4 GHz
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Cables included	LAN (RJ-45)
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	108.7 mm
Width	48 mm
Height	132.46 mm
Weight	163 g
