Hardware Setup
9
N300 WiFi Router
Rear Panel
The rear panel has the connections and button shown the following figure.
Power adapter input
Ethernet LAN ports
Power On/Off button
Internet port
Figure 3. Router rear panel
Position Your Router
The router lets you access your network anywhere within the operating range of your
wireless network. However, the operating distance or range of your wireless connection can
vary significantly depending on the physical placement of your router. For example, the
thickness and number of walls the wireless signal passes through can limit the range.
Additionally, other wireless access points in and around your home might affect your router’s
signal. Wireless access points are routers, repeaters, WiFi range extenders, and any other
device that emits a wireless signal for network access.
Position your router according to the following guidelines:
• Place your router near the center of the area where your computers and other devices
operate and within line of sight to your wireless devices.
• Make sure that the router is within reach of an
AC power outlet and near Ethernet cables
for wired computers.
• Place the router in an elevated location, minimizing the number walls and ceilings
between the router and your other devices.
• Place the router away from electrical devices such as these:
- Ceiling fans
- Home security systems
