Hardware Setup
18
Trek N300 Travel Router and Range Extender PR2000
To use the Trek as a WiFi range extender:
1. Place the T
rek at an equal distance between your existing WiFi router and the wireless
device that is located in the dead zone of your router.
DO DON’T
NETGEAR
Power
Internet
WiFi
USB
Wired
Power Off
Wireles
NETGEAR
Power
Internet
WiFi
USB
Wired
Power Off
Wireles
When possible, have your Trek in the same room with your existing router when you
specify the settings of the Trek.
2. Connect the Trek to a power source.
For more information, see Power Inputs on page 13.
3. T
urn on power to the Trek by moving the Internet via switch from the Power Off position to
the Wireless position.
4. Rotate the Trek’
s cover clockwise to orient the antenna.
For more information, see Antenna Orientation on page 14.
5. Connect your computer or wireless device to the T
rek's SSID, or connect your computer or
wireless device to the Trek’s LAN port with an Ethernet cable.
6. Open a web browser on your computer
, type www.routerlogin.net in the address field, and
press the Enter key.
If a login screen displays, enter admin for your user name and password for your
password.
The user name and password are case-sensitive. Then click the OK button.
The Wireless as WAN screen displays, which shows the available wireless networks.
7. Make sure that the Extend my current wireless router's range check box is selected.
