Troubleshooting with the LEDs
The LEDs can help you troubleshoot the hardware.
Power LED Is Off
The switch has no power. Make sure that:
• The power cord is correctly connected to the switch.
• The power adapter is correctly connected to a functioning power outlet. If you
are using a power strip, make sure the power strip is turned on. If the socket is
controlled by a light switch, make sure the switch is in the on position.
• You are using the NETGEAR power adapter supplied with your switch.
Port LED Is Off or Stays On
There is a hardware connection problem.
• Make sure the cable connectors are securely plugged in at the switch and the
device.
• Make sure the connected device is turned on.
• If the Ethernet cable is connected to an NIC or other Ethernet adapter, make
sure the card or adapter is installed correctly and is working.
• Make sure the cable is less than 328 feet (100 meters).
Technical specifications
Standards compatibility IEEE 802.3i 10BASE-T Ethernet, IEEE 802.3u 100BASE-
TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit
Ethernet, IEEE 802.3x Flow Control, IEEE 802.1p and TOS
priority, WRR queuing with four queues
Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or
1000BASE-T Ethernet interface
Power adapter 12W max. and 12V@ 1A DC input
Power consumption 9.5W max.
Weight 895g (1.973 lb.)
Dimensions
(W x D x H)
286 mm x 101 mm x 27 mm
11.26 in. x 3.98 in. x 1.06 in.
Operating temperature 0 to 50° C (32 to 122° F)
Operating humidity 10% to 90% relative humidity, non-condensing
Electromagnetic compliance CE Class A, included EN55022 (CISPR 22) and EN55024,
FCC part 15 Class A, VCCI Class A, C-Tick Class A
Power adapter safety agency
approvals
CE mark, Commercial UL listed (UL 60950-1), C-Tick, CB,
& CCC
Technical Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product,
and use it to register your product at www.NETGEAR.com/register. Registration is
required to use our telephone support service. Also go to http://support.netgear.com
for product updates, additional documentation, and support.
For complete DoC go to the NETGEAR EU Declarations of Conformity website at
http://support.netgear.com/app/answers/detail/a_id/11621/.
Performance specifications
Frame filter rate 14,880 frames/sec. max. for 10 M port; 148,800 frames/sec.
max. for 100 M port; 1,488,000 frames/se.c max. for 1000 M
port
Frame forward rate 14,880 frames/sec. max. for 10 M port; 148,800 frames/sec.
max. for 100 M port; 1,488,000 frames/sec. max. for 1000 M
port
Network latency
(using 64-byte packets)
100 Mbps to 100 Mbps: 5.2 μs max.
1000 Mbps to 1000 Mbps: 2.6 μs max.
Address database size Up to 8K MAC addresses
MAC address learning Automatically updated
Queue buffer 2 Mb
Jumbo frame support Up to 9 KB
NETGEAR Green features Auto power-down mode saves energy when ports are unused
Power-saving per port if the cable length is less than 32.8 feet
(10 meters).
GS116 IG.fm Page 2 Wednesday, February 8, 2012 10:07 AM
