NETGEAR R6080 User Manual

The user name is admin. The default password is password. The user name and
password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
Wired devices are connected to the router with Ethernet cables. Wireless devices
are connected to the router through the WiFi network, in either the 2.4 GHz band
or one of the 5 GHz bands.
The following table describes the fields that can be displayed.
DescriptionField
The status of the device in the network (Allowed or Blocked).Status
The name of the WiFi network to which the device is connected.SSID
The IP address that the router assigned to the device when it joined the network. This
address can change when a device is disconnected and rejoins the network.
IP Address
The unique MAC address. The MAC address does not change and is usually shown on
the product label.
MAC Address
The device name, if detected.Device Name
The type of connection for the device.Connection
Type
5.
To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
User Manual105Manage the Router
AC1000 WiFi Router Model R6080

NETGEAR R6080 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	700 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	4
Product type	Tabletop router
Product color	Black
Antennas quantity	2
Power source type	DC
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	136.5 mm
Width	185 mm
Height	46 mm
Weight	250 g
