Page #14 background imageLoading...
Page #14 background image
information, see Manage Ethernet port aggregation to a LAN device on page
86.
You can set up both Internet (WAN) aggregation and LAN aggregation.
5. USB 3.0 port. Use the USB 3.0 port to connect a USB storage device to your router.
6. Power On/Off button. Press the Power On/Off button to provide power to the
router.
7. DC power connector. Connect the power adapter that came in your product package
to the DC power connector.
Extend the antennas
Before you install your router, extend the antennas as shown in the following figure.
Figure 4. Extend the antennas
Router label
The router label shows the login information, WiFi Network Name (SSID), network key
(password), serial number, and MAC address. The following image is an example of
what your router label might look like:
Figure 5. Router label
User Manual14Hardware Setup
Nighthawk AX8 8-Stream Tri-Band WiFi 6 Router

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR RAX70 and is the answer not in the manual?

NETGEAR RAX70 Specifications

General IconGeneral
WiFi SpeedUp to 6.6Gbps
WiFi BandsTri-Band
USB Ports1 x USB 3.0
BeamformingYes
MU-MIMOYes
OFDMAYes
WiFi Technology802.11ax
ProcessorQuad-Core 1.5 GHz
Antennas6
SecurityWPA3
Memory512MB RAM
Ethernet Ports5 (1 x 2.5 Gbps WAN, 4 x 1 Gbps LAN)
