Table 1. LED descriptions (Continued)
DescriptionLED
Solid green. One or both WiFi radios are operating.
Blinking green. One or both WiFi radios are sending or receiving traffic.
Blinking green slowly. Someone pressed the WPS button.
Off. Both WiFi radios are off. For more information, see WiFi LED Is Off on page 245.
WiFi
Solid green. A USB device is connected and is ready.
Off. No USB device is connected.
USB
Back panel with ports, buttons, and a power
connector
The back panel of the access point/router provides ports, buttons, and a DC power
connector.
Figure 2. Access point/router back panel
User Manual13Hardware Overview of the
Access Point/Router
AC2000 802.11ac Wireless Access Point/Router WAC124
