NETGEAR WAC720 User Manual

Hardware Setup
7
ProSAFE Dual-Band Wireless AC Access Points WAC720 and WAC730
Unpack Your Access Point
Your package contains the following items:
• ProSAFE Dual-Band Wireless AC Access Point
• Straight-through Category 5 Ethernet cable
• Ceiling and wall installation kit
• Installation guide
Contact your reseller or customer support in your area if any parts are missing or damaged.
Visit the NETGEAR website at support.netgear.com/general/contact/default.aspx for the
telephone number of customer support in your area.
Hardware Description
The following sections describe the top and rear hardware functions of the access point.
• Top Panel
• Rear Panel
• Bottom Panel With Product Label
Top Panel
The LEDs of the access point are described in the following figure and table:
Figure 1. Top panel
1
23
4
5
