NETGEAR WAC720 User Manual

Hardware Setup
9
ProSAFE Dual-Band Wireless AC Access Points WAC720 and WAC730
The rear panel components of the access point, from left to right, are described in the
following list:
1. Cable security lock receptacle for an optional lock.
2. Console port for connecting to an optional console terminal. The port provides an RJ-45
connector and supports the following settings: 115200 K default baud rate, 8 data bits, no
(N) parity bit, and one (1) stop bit.
3. Factory default Reset button. Using a sharp object, press and hold this button for about
five seconds to reset the access point to factory defaults settings. All configuration settings
are lost, and the default password is restored. For more information, see Restore the Access
Point to the Factory Default Settings on page 62.
4. 10/100/1000BASE-T Gigabit Ethernet (RJ-45) port with Auto Uplink (Auto MDI-X) and
support for IEEE 802.3af Power over Ethernet (PoE) for connection to a switch or router that
can provide PoE.
5. Power socket for an optional 12 VDC, 2.5A power adapter.
Note: The WAC720 access point can support up to two optional
2.4 GHz/5 GHz dual-band antennas. The WAC730 access point can
support up to three optional 2.4 GHz/5 GHz dual-band antennas.
Bottom Panel With Product Label
The product label on the bottom of the access point’s enclosure displays factory default
settings, regulatory compliance, and other information.
Figure 3. Product labels
䗃ޕ: 12V 2.5A
272-12481-02 制造商: NETGEAR, INC.
FCC ID: PY315300321 IC: 4054A-15300321
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
ύ㡚ڋ೷!Made in China
CMIIT ID: XXXXXXXXXX
产品型号: WAC730 ӗ૱〠ৼ仁⇥ᰐ㓯AC᧕ޕ⛩
序列号
䗃ޕ: 12V 2.5A
272-12480-02
FCC ID: PY315300320 IC: 4054A-15300320
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
ύ㡚ڋ೷!Made in China
CMIIT ID: XXXXXXXXXX
产品型号: WAC720 ӗ૱〠ৼ仁⇥ᰐ㓯AC᧕ޕ⛩
序列号
XXX-XXXXXX
XXXXXXXXXX
W52/W53 Ȅቻ޵䲀ᇊ
制造商: NETGEAR, INC.
