NETGEAR WGR614 v5 User Manual

Reference Manual for the 54 Mbps Wireless Router WGR614 v5
Introduction 2-7
June 2004 202-10036-01
The Router’s Rear Panel
The rear panel of the WGR614 v5 router contains the items listed below.
Figure 1-2: WGR614 v5 Rear Panel
Viewed from left to right, the rear panel contains the following features:
• AC power adapter outlet for 12 V DC @ 1A output, 22W maximum
• Four Local (LAN) 10/100 Mbps Ethernet ports for connecting the router to the local
computers
• Internet (WAN) Ethernet port for connecting the router to a cable or DSL modem
• Factory Default Reset push button for Restoring the Default Configuration and Password
• Wireless antenna
A Road Map for ‘How to Get There From Here’
The introduction and adoption of any new technology can be a difficult process. Broadband
Internet service is considered so useful that more and more people want to set up networks in their
home to share a broadband connection. Wireless technology has removed one of the barriers to
networking—running wires. It allows more people to try networking while at the same time
Power
4 LAN Ports
Internet Port
Reset
Wireless
4
32
1
Antenna
Button

NETGEAR WGR614 v5 Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Wireless Data Rates	Up to 54 Mbps
Firewall	NAT, SPI
Power Supply	12V DC, 1A
Weight	0.3 kg
Dimensions	175 x 118 x 28 mm
