Reference Manual for the 54 Mbps Wireless Router WGR614 v5
3-4 Connecting the Router to the Internet
July 2004 202-10036-01
Figure 3-4: Verify the connections according to the status lights on the wireless router
d.
Check the wireless router status lights to verify the following:
• Power: The power light should turn solid green. If it does not, see “Troubleshooting
Tips” on page 3-8.
• Test: The test light blinks when the router is first turned on, then goes off. If after 2
minutes it is still on, see “Troubleshooting Tips” on page 3-8.
• Internet: The Internet port light should be lit. If not, make sure the Ethernet cable is
securely attached to the wireless router Internet port and the modem, and the modem
is powered on.
• Wireless: The Wireless light should be lit. If the Wireless light is not lit, see
“Troubleshooting Tips” on page 3-8.
• LAN: A LAN light should be lit. Green indicates your computer is communicating at
100 Mbps; yellow indicates 10 Mbps. If a LAN light is not lit, check that the Ethernet
cable from the computer to the router is securely attached at both ends, and that the
computer is turned on.
3. USE THE SMART WIZARD TO CONFIGURE THE WIRELESS ROUTER
a. From the Ethernet connected PC you just set up, open a browser such as Internet Explorer
or Netscape® Navigator.
0OWER
)NTERNET0ORT
7IRELESS
,!.0ORT
4EST

NETGEAR WGR614 v5 Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Wireless Data Rates	Up to 54 Mbps
Firewall	NAT, SPI
Power Supply	12V DC, 1A
Weight	0.3 kg
Dimensions	175 x 118 x 28 mm
