Router Setup Manual
Connecting the Router to the Internet 1-7
v1.0, 2006-01-17
c. Last, turn on your computer.
d. Check the router status lights to verify the following:
• Power: The power light (1) should turn solid green. If it does not, see “Quick Tips” on
page 2-1.
• Test: The test light (2) blinks when the router is first turned on, then goes off. If after 2
minutes it is still on, see “Quick Tips” on page 2-1.
• Wireless: The Wireless light (3) should be off. The Smart Wizard configuration
assistant turns on and sets up the wireless feature of your router.
• Internet: The Internet port light (4) should be lit. If not, make sure the Ethernet cable
is securely attached to the router Internet port and the modem, and the modem is
powered on.
• LAN: A LAN light (5) should be lit. Green indicates your computer is communicating
at 100 Mbps; amber indicates 10 Mbps. If a LAN light is not lit, check that the
Ethernet cable from the computer to the router is securely attached at both ends, and
that the computer is turned on.
Note: For DSL customers, if software logs you in to the Internet, do not run that
software. You may need to go to the Internet Explorer Tools menu, Internet
Options, Connections tab page where you can select “Never dial a connection.”
Figure 1-6
2341
5
