NETGEAR WN3000RP Installation Guide

7
Connect with WPS
Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network
without typing the network name and password.
WPS does not support WEP network security. If you are using WEP
security, follow the instructions in Connect with NETGEAR genie
Smart Setup on page 8.
1. Press the WPS button on the side panel of the extender.
The WPS LED blinks.
2. Within two minutes, press the WPS button on your router or access
point.
The WPS LED on the extender lights solid green, the Router Link
LED lights, and the extender connects to your existing WiFi
network.
Note: If the Router Link LED does not light, try again. If it still
does not light, see Connect with NETGEAR genie Smart Setup
on page 8.
3. Find the new extender network name.
The extender’s wireless network name (SSID) changes to your
existing WiFi network name, with _EXT at the end of the name,
for example:
• Existing WiFi network name. MyNetworkName

NETGEAR WN3000RP Specifications

General

Interface	Ethernet
Connectivity technology	Wireless
Wi-Fi band	Single-band (2.4 GHz)
Ethernet LAN	Yes
Security algorithms	WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Chipset	-
Internal	No
Certification	RoHS, WEEE, CEC
Component for	PC/Laptop
Product color	White
Dimensions (WxDxH)	112 x 74 x 45 mm
Minimum system requirements	802.11 b/g/n 2.4 GHz wireless router or gateway 802.11 b/g/n 2.4 GHz wireless adapter or Ethernet adapter and cable for each computer
Compliance industry standards	IEEE 802.11 b/g/n
Compatible operating systems	Windows 7, Vista, XP, 2000 Mac OS UNIX Linux

Weight and Dimensions

Weight	245 g
