NETGEAR XAVB5501 User Manual

Appendix A. Supplemental Information | 24
A
A. Supplemental Information
This appendix provides technical specifications and safety information for the XAV5501
Powerline AV+ 500 Adapter.
Technical Specifications
Network Protocol and Standards Compatibility
Data and routing protocols: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx),
IEEE 802ab 1000BASE-T
AC input 100–240V~, 0.2A (Max)
Power consumption: 5W
Dimensions: Height: 98 mm
Width: 72 mm
Depth: 40 mm
Weight: 0.4 lbs (0.18 kg)
Environmental Specifications
Operating temperature: 0° to 40° C (32º to 104º F)
Operating humidity: 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security
Encryption type: 128-bit AES
Bridge Performance
MAC addresses: 64
Bandwidth 500 Mbps
Powerline Performance
Compatibility: HomePlug AV
Data Transfer Rate: Up to 240 Mbps

NETGEAR XAVB5501 Specifications

General

Brand	NETGEAR
Model	XAVB5501
Category	Adapter
Language	English
