150Mbps Wireless-N Broadband Router Quick Installation Guide
3
SYS Flashing
Power on
Router system running
WPS working (orange)
On WAN Connection normal
WAN
Flashing Data transmitting
On LAN Connection normal
LAN
Flashing Data transmitting
5. Configure Your Computer
You can manage the 150Mbps Wireless-N broadband router through the Web browser- based
configuration utility. To configure the device via Web browser, at least one properly
configured computer must be connected to the device via Ethernet or wireless network. The
router is configured with the default IP address of 192.168.1.1 and subnet mask of
255.255.255.0 and its DHCP server is enabled by default.
Here we use Windows XP for example. If your network settings are not already set and
you need to complete this step, the configurations are similar for the other operating
systems.
¾ Open My Computer on your desktop or through the Start menu, right click on My
Network Places in the Other Places menu to the left and select Properties. Right click
on your Local Area Connection in the window that appears and select Properties. In the
properties window that appears, under “This connection uses the following items:” select
Internet Protocol (TCP/IP) and then click the Properties button below.
