2.2 Slot Board Layout
1. Slot 1 : PCIe ×16 connector (×16 signal)
Target card already installed in it
2. Slot 2 : PCIe ×16 connector (×8 signal)
3. Slot 3 : PCIe ×16 connector (×8 signal)
4. Slot 4 : PCIe ×16 connector (×8 signal)
5. Slot 5 : PCIe ×16 connector (×8 signal)
6. 4×6+2 pin PCIe power cables & 4×6-pin PCIe power cables for cards
