NetterVibration PKL Series User Manual

Technical data
8
Type:
PKL ...
Weight
of piston
[kg]
Force of
impact *
[kg]
Optimum
operating
pressure
[bar]
Air consump-
tion/impact at opti-
mum pressure
[Nl]
Overall
weight
[kg]
Suitable
for wall
thickness
of...
[mm]
190/4
0.19
0.43
4.0
0.20
0.8
1 - 2
190/6
0.19
0.60
6.0
0.20
0.8
1 - 2
450/4
0.44
0.56
4.0
0.40
1.6
1 - 3
450/6
0.44
0.92
6.0
0.60
1.6
1 - 3
740/3
0.74
1.30
3.0
0.50
2.6
2 - 4
740/4
0.74
1.80
4.0
0.70
2.6
2 - 4
740/5
0.74
2.10
5.0
0.80
2.6
2 - 4
740/6
0.74
2.70
6.0
1.00
2.6
2 - 4
1000/4
1.00
2.80
4.0
2.70
5.7
2 - 4
1000/6
1.00
4.30
6.0
4.00
5.8
3 - 5
2100/4
2.10
4.20
4.0
5.20
6.7
3 - 5
2100/5
2.10
6.20
5.0
6.50
6.9
3 - 5
5000/4
4.96
6.60
4.0
5.70
16.0
4 - 8
5000/6
4.96
10.60
6.0
8.60
16.5
6 - 12
10000/6
10.00
17.50
6.0
15.10
34.0
> 10
* The force of impact corresponds to the impact of the given weight falling from a height of 1 m.
PKL 190
PKL 450
PKL 740
Type:
PKL ...
A
[mm]
B
[mm]
C
[mm]
Ø D
[mm]
E
[mm]
F
1
G
[mm]
H
[mm]
H*
[mm]
190
38.0
111
15
9.0
-
G 1/8,
DN 6 × 1
90.0
163.5
169.5
450
73.5
126
14
13.0
-
90.0
192.0
200.0
740
90.0
140
15
13.0
50
100.0
238.5
248.5
* with EE kit
1
DN = nominal diameter
Parameters
Dimensions
PKL
190 /
450 /
740
